| X axis | 1500mm | Spindle motor power | 11/15KW |
| Y axis | 1500mm | Spindle motor torque | 72/98N.m |
| Z axis | 600mm | Rapid Traverse(X/Y/Z) | 10/10/7m/min |
| Gantry span | 1500mm | Servo motor power(X/Y/Z) | 5.1/3.6/4.7KW |
| Distance from spindle nose to table | 150-750mm | Servo motor torque(X/YIZ) | 28/18/23N.m |
| Table Size | 1500*1200mm | Servo motor speed(X/Y/Z) | 2000rpm |
| Table Load | 3T | Ball screw diameter(X/YIZ) | 50/50/50mm |
| T- Slot (Width x Number x Pitch) | 22/5/7160mm | Cutting feedrate | 6000mm/min |
| Spindle Speed | 3,000(6,000-opt.) | Minimum step equivalent | 0.001mm |
| Spindle Taper | BT-50/ISO-50/CAT-50 | CNC system | FANUCISINUMERIK/SYNTEC/KND |
