Technical Parameters
| X axis | 800mm | Spindle motor power | 11/15KW |
| Y axis | 550mm | Disc type tool magazine | 24T |
| Z axis | 550mm | Rapid Traverse(X/Y/Z) | 48/48/48m/min |
| Distance from spindle center to column | 590mm | Servo motor torque(X/Y/Z) | 15/15/28N.m |
| Distance from spindle nose to table | 120-670mm | positioning accuracy | ±0.005mm |
| Table Size | 1000*550mm | Repeatability | ±0.003/300mm |
| Table Load | 600kg | Rail widthX/Y/Z) | RGH35/45/45 |
| T- Slot (Width x Number x Pitch) | 18/5/90mm | Minimum step equivalent | 0.001mm |
| Spindle Speed | 8000 rpm | CNC system | FANUC/SINUMERIK/SYNTEC/KND |
| Spindle Taper | BT-40/ISO-40/CAT-40 |
